Sumitomo Electric Lightwave’s Indoor NEMA 1-Rated Tube Distribution Units (TDUs) feature a scalable and flexible design, serving as wall-mountable enclosures used at tube cable transitions or branching locations. Tube cables joined together using push-fit connectors within the enclosure, facilitating pathways between various TDUs or termination points in the network. In addition, optional perforated back panel kits are available for enhanced tube and cable management.

Find a Distributor

Product Downloads

Product Information

Download

Ordering Information

PART NUMBERRATINGTUBE CAPACTIYMATERIALCOLORWEIGHTDIMENSIONS
(W. x H. x D.)
DE20IDUNEMA-184 Tubes (approx.)SteelGray27 lb (12.3 kg)20 x 20 x 7 in (508 x 508 x 178 mm)
DE36IDUNEMA-1168 Tubes (approx.)SteelGray70 lb (31.8 kg)30 x 36 x 7 in (762 x 914 x 178 mm)

Accessories

PART NUMBERDESCRIPTION
DE20IDUPPerforated Back Panel Kit for DE20IDU.
DE36IDUPPerforated Back Panel Kit for DE36IDU.
DEIDUKEYcylinder key lock kit with two keys for DE20IDU, and DE36IDU.
DEIDUKEY2two replacement keys for DEIDUKEY.
DEDTTPRack-Mounted Tube Distribution Hardware (Standard Capacity); Holds up to Twelve (12) 7-Tube Cables (84 Tubes Total)
DEDTTP2Rack-Mounted Tube Distribution Hardware (High Capacity); Holds up to Six (6) 19-Tube Cables (114 Tubes Total)

Features

Features

  • Protective stainless-steel frame
  • NEMA-1 Rating
  • Hinged door secured with slotted latch
  • Top-left, top-right, bottom-left, and bottom-right cable entry/exit area
  • Replacement hinge for key lock
  • Perforated back panel kits for additional tube management

Benefits

  • Protects transition tubes
  • High tube capacity
  • Low-profile design suitable for multiple indoor locations
  • Reduces risk of dust or particulate matter from entering
  • Facilitates efficient distribution of pathways between locations
