Q102-CA+
The Q102-CA+ offers improved splicing performance, reliability, and overall experience with our new features and technologies, while maintaining all of the industry-leading features of its predecessor, the Q102-CA, including its world-class*2 light and compact frame, quick splicing, and environmental durability.
Product Downloads
Ordering Information
Fusion Splicer Kits
| Part Number | Description |
|---|---|
| TYPE-Q102-CAp-KIT-1 | TYPE Q102-CA+ Quantum Fusion Splicer Kit includes Fiber Stripper (JR-M03), One Pack of Fiber Protection Sleeves, Shipping Case, one set of Spare Electrodes (ER-10), AC Interface/Battery Charger with Power Cord, Battery Unit (BU-102) |
| TYPE-Q102-CAp-KIT-2 | TYPE Q102-CA+ Quantum Fusion Splicer Kit includes Precision Cleaver (FC-6S-C), Fiber Stripper (JR-M03), One Pack of Fiber Protection Sleeves, Shipping Case, one set of Spare Electrodes (ER-10), AC Interface/Battery Charger with Power Cord, Battery Unit (BU-102) |
| TYPE-Q102-CAp-KIT-6RSC | TYPE Q102-CA+ Quantum Fusion Splicer Kit includes Precision Cleaver w/ Auto Rotating Blade (FC-6RS-C), Fiber Stripper (JR-M03), One Pack of Fiber Protection Sleeves, Shipping Case, one set of Spare Electrodes (ER-10), AC Interface/Battery Charger with Power Cord, Battery Unit (BU-102) |
| TYPE-Q102-CAp-KIT-6RSCFH | TYPE Q102-CA+ Quantum Fusion Splicer Kit includes 250um, 900um and Loose Buffer Fiber Holders, Precision Cleaver w/ Auto Rotating Blade (FC-6RS-C), Fiber Stripper (JR-M03), One Pack of Fiber Protection Sleeves, Shipping Case, one set of Spare Electrodes (ER-10), AC Interface/Battery Charger with Power Cord, Battery Unit (BU-102) |
| TYPE-Q102-CAp-KIT-8R | TYPE Q102-CA+ Quantum Fusion Splicer Kit includes Precision Cleaver w/ Auto Rotating Blade (FC-8R), Fiber Stripper (JR-M03), One Pack of Fiber Protection Sleeves, Shipping Case, one set of Spare Electrodes (ER-10), AC Interface/Battery Charger with Power Cord, Battery Unit (BU-102) |
| TYPE-Q102-CAP-KIT-8RFH | TYPE Q102-CA+ Quantum Fusion Splicer Kit includes 250um, 900um and Loose Buffer Fiber Holders, Precision Cleaver w/ Auto Rotating Blade (FC-8R), Fiber Stripper (JR-M03), One Pack of Fiber Protection Sleeves, Shipping Case, one set of Spare Electrodes (ER-10), AC Interface/Battery Charger with Power Cord, Battery Unit (BU-102) |
Accessories
| Part Number | Description |
|---|---|
| FHS-025 | For 0.25mm single fiber |
| FHS-09 | For 0.9 mm single fiber |
| FHS-025-LB5-L250um | Loose Buffer Holder – Left Side |
| FHS-025-LB5-SET250um | Loose Buffer Holder Set (L&R) |
| LYNX2-HOLDER-C | Lynx CustomFit™’ SOC Ferrule Holder |
| LYNX2-HOLDER-S | Lynx CustomFit™ SOC Ferrule Holder (FPS Holder) |
| BU-102 | Battery Pack, Li-ion 6,400mAh |
| BC-102 | Battery charger |
| PCV-16 | For car battery operation (cigarette socket) |
| VGB-003-CR | Brush for cleaning V-groove |
| ER-10 | Electrodes |
| FC-8R | Automatic blade rotation cleaver with cleave counter |
| FC-6RS-C | Automatic blade rotation cleaver |
| JR-M03 | Jacket remover for single fiber |
| FPS-1 | 60mm, diameter after shrink approx. 3.2mm |
| FPS-40 | 40mm, diameter after shrink approx. 3.2mm |
| FPS-61-2.6 | 61mm, diameter after shrink approx. 2.6mm |
How-To Videos
See All Videos
Part of Sumitomo Electric Lightwave’s How -To video series. This guide provides a thorough introduction to assembling an LC Splice-On Connector with Sumitomo Electric’s Q502S Fusion Splicer on Cordage
Features
Preventative Maintenance
Its Preventive Maintenance feature enables users to be alerted of upcoming repairs or consumable replacement, thus reducing unexpected downtime. SumiCloud™*3 supports this function with wireless LAN connectivity*4.
Quick Mode
The Q102-CA+ can splice in 5 seconds in Quick Mode, and has an improved heating time of 8 seconds.
Reduced Power Consumption
In addition to a variety of highly regarded functions inherited from its predecessor, such as the lightweight and compact design and shock-proof, dust-proof, and drip-proof frame, the Q102-CA+ saves power consumption by 7% with a newly employed heat-resistant material, thereby enabling 320 operation cycles on a full charge.
NanoTune Technology
The Q102-CA+ is equipped with NanoTune™ technology, which greatly improves splicing efficiency and accuracy regardless of operational condition and user skill, with the use of AI algorithms. The Q102-CA+ drastically reduces the need of splice reworks caused by insufficient fiber preparation such as poor cleaving, thus reducing overall costs.
Additional Features
- Dual independent heat shrink ovens
- Fastest Splicer with 5 sec. Splice time and Dual 9 Sec Heaters
- WVGA High Resolution, Fully Navigational Touch Screen Monitor
- SD Port for Virtually Unlimited Data Storage
- Internet Interface for Remote Maintenance & Software Upgrades
- Smartphone-Like User Interface
- Wide Angle LED Work Area Illumination
- Dual independent heat shrink ovens
- Fastest Splicer with 5 sec. Splice time and Dual 9 Sec Heaters
- WVGA High Resolution, Fully Navigational Touch Screen Monitor
- SD Port for Virtually Unlimited Data Storage
- Internet Interface for Remote Maintenance & Software Upgrades
- Smartphone-Like User Interface
- Wide Angle LED Work Area Illumination
